VEHICLE HEIGHT GUIDE
Compare vehicle dimensions and preliminary stacker clearances before finalizing floor levels and ceiling heights.
Product Height Configurations
Double-High Stacker
Total: 13'-3 1/8" (6' upper) · 12'-0 1/8" (4'-9" upper)
The stacker height can be customized based on building requirements.
View common vehicle classes and models to compare height, width, length, and fit across the available configurations.
Product Height Configurations
Triple-High Stacker
Dimensions
Self-Parking Stackers
*The dimensions shown are standard configurations and are provided for reference purposes only. Further customizations are possible.
Looking for Fully Automated Parking Height Requirements?
Floor-to-ceiling clearances depend on vehicle mix, system technology, and local structural codes. Get an exact dimensional analysis customized for your project floor plan.
Parking Planning Resource
Vehicle Height Reference
Select a vehicle class and model to compare height, width, length and fit across the listed configurations.
Reference dimensions use U.S.-market manufacturer-published specifications for a representative 2025 or 2026 configuration. Width is shown without mirrors unless the manufacturer states otherwise. Dimensions can vary by trim, drivetrain, model-year update, wheel and tire package, suspension, roof rails, accessories, or aftermarket modifications. This tool is a planning reference, not final clearance approval. Verify the exact vehicle and required safety clearance before selecting, designing, ordering, or operating a parking stacker.
Keep parking height specs at your fingertips.
Use the Parking Height Reference Guide to compare representative vehicle dimensions and preliminary clearances for AutoMotion stacker configurations.
Bookmark it, reference it, and use it throughout your design and planning process.
